QUICK REFERENCE
Cisco Unified IP Conference
Station 7937 for
Cisco Communications
Manager Express
This quick reference is intended for Cisco
Unified IP phone users who are already
familiar with their phones.
Note Because of differences in phone
models and features, not all
procedures and soft keys
described here apply to all
phones.
Using the Quick Reference Card
• Complete numbered items in sequence.
• Choose only one bulleted item.
• Bold terms identify soft keys.
Feature Function
1 LED
Indicators
Three multi-color LED
indicators provide call status
information:
•Off: Ready, Call State Off
•Solid amber: Powering On
•Solid red: Powering On,
Mute, or Voice Message
•Flashing red: Hold
•Solid green: Dial Tone,
Dialing, or Connected
•Flashing green: Incoming
Call (Ringing/Connecting),
or Receiving
2 Microphones Three internal unidirectional
microphones
3 Speaker Internal Speaker
4 Navigation
Button
Allows the user to scroll
through menus and highlight
items.
5 Select Button Activates the currently
highlighted screen menu
option
6 On-hook
Button
Ends Current Call.
7 Volume Up
Button
Raises the volume of the
speaker (off-hook) and the
ringer (on-hook).
8 Volum e
Down Button
Lowers the volume of the
speaker (off-hook) and the
ringer (on-hook).
9 Mute Button Toggles the Mute feature.
10 Keypad Allows the user to dial phone
numbers, enter letters, and
choose menu items
11 Redial
Button
Dials the most recent number
you called
12 Directories
Button
Toggles the Directories menu.
Allows the user to access
speed dials and directories.
13 Application
Button
Toggles the Applications
menu. Allows the user to
access the Messages, Settings,
and Services menus
14 Off-hook
Button
Allows the user to go
off-hook to:
• Invoke a dial tone
• Obtain a dial tone to
initiate a call
• Initiate a call after you
enter a phone number
• Answer an incoming call
• View certain soft keys
15 Soft keys
Button
Allows the user to select soft
key options that display on
the screen.
16 Conference
Station
Screen
Displays conference station
menus and features.
Feature Function
