Cisco 860 Series Installation Guide

A-25
Cisco Integrated Services Router Hardware Installation Guide
OL-27407-02
Appendix A Technical Specifications
Cisco 860, 880, 890 Series
ADSL2+ Port Connector Pinouts
Table A-22 lists the ADSL2+ connector pinouts.
V.92 Port Connector Pinouts
Table A-23 lists the V.92 connector pinouts.
G.SHDSL Port Connector Pinouts
Table A-24 lists the pinouts for the symmetrical high-speed DSL (G.SHDSL) WAN port for two-pair
products, including the following router model(s):
• C888
5Unused
6Unused
Table A-21 VDSL2 Connector Pinouts (RJ-11-to-RJ-45) (continued)
RJ-11 Pin Function
Table A-22 ADSL2+ Connector Pinouts (RJ-11)
RJ-11 Pin Function
1Unused
2Unused
3TIP
4RING
5Unused
6Unused
Table A-23 V.92 Connector Pinouts (RJ-11-to-RJ-45)
RJ-11 Pin Function
1Unused
2Unused
3TIP
4RING
5Unused
6Unused

Cisco 860 Series Specifications

General

VPN Support	Yes
Firewall	Yes
QoS	Yes
Data Link Protocol	Ethernet, Fast Ethernet
Remote Management Protocol	SNMP, Telnet, HTTP, HTTPS
Operating System	Cisco IOS
Device Type	Router
WAN Interfaces	1 x 10/100Base-TX - RJ-45
LAN Interfaces	4 x 10/100Base-TX - RJ-45
Connectivity Technology	Wired
Network / Transport Protocol	IPSec, TCP/IP
Features	DHCP support, NAT support, VLAN support, IPv6 support
Compliant Standards	IEEE 802.3, IEEE 802.3u
