Cisco 860 Series Installation Guide

A-26
Cisco Integrated Services Router Hardware Installation Guide
OL-27407-02
Appendix A Technical Specifications
Cisco 860, 880, 890 Series
Table A-25 lists the pinouts for the symmetrical high-speed DSL (G.SHDSL) WAN port for four-pair
products, including the following router models:
• C888E
• C888EW
• C888EA
Data BRI Port Connector Pinouts
Table A-26 lists the pinouts for the Data BRI port.
Table A-24 G.SHDSL WAN Port Pinouts for Two-Pair Products
Pin Function
1Unused
2 TIP (Port1)
3 TIP (Port0)
4 RING (Port0)
5 RING (Port1)
6Unused
Table A-25 G.SHDSL WAN Port Pinouts for Four-Pair Products
Pin Function
1 TIP (Port1)
2 RING (Port1)
3 TIP (Port2)
4 TIP (Port0)
5 RING (Port0)
6 RING (Port2)
7 TIP (Port3)
8 RING (Port3)
Table A-26 Data BRI Port Pinouts
Pin Function
1Unused
2Unused
3TXP
4RXP
5TXN
6TXN

Cisco 860 Series Specifications

General

VPN Support	Yes
Firewall	Yes
QoS	Yes
Data Link Protocol	Ethernet, Fast Ethernet
Remote Management Protocol	SNMP, Telnet, HTTP, HTTPS
Operating System	Cisco IOS
Device Type	Router
WAN Interfaces	1 x 10/100Base-TX - RJ-45
LAN Interfaces	4 x 10/100Base-TX - RJ-45
Connectivity Technology	Wired
Network / Transport Protocol	IPSec, TCP/IP
Features	DHCP support, NAT support, VLAN support, IPv6 support
Compliant Standards	IEEE 802.3, IEEE 802.3u
