Cisco 897VA User Manual

1-112
Cisco Integrated Services Router Hardware Installation Guide
Chapter 1 Product Overview
Cisco 860, 880, 890 Series
3 GE LAN 0
GE LAN 1
GE LAN 2
GE LAN 3
Green/Yellow Off—No link.
Green On—Link.
Yellow On—Fault with PoE. Implies no link.
Green Blinking—Data is either being received or
transmitted.
4 GE LAN 4
GE LAN 5
GE LAN 6
GE LAN 7
Green Off—No link.
On—Link.
Blinking—Data is either being received or being
transmitted.
5 GE WAN 8 Green Off—No link.
On—Link.
Blinking—Data is either being received or being
transmitted.
SFP WAN 8 Green Off—No link.
On—Link.
Blinking—Data is either being received or being
transmitted.
6 VPN Green Off—No tunnel.
On—At least one tunnel is up.
7 PPP Green Off—No PPP session.
On—At least one PPP session established.
8 xDSL CD0 Green Off—Interface is shutdown.
On—Showtime, Link up.
Slow Blinking—Modem initialization.
Fast Blinking—Training up the line.
If both CD0 & CD1 are ON then VDSL Bonding is
active.
xDSL CD1
xDSL DATA Green Off—No Data.
Blinking—Data is either being received or transmitted.
9 ISDN B1 Green Blinking—Data is either being received or transmitted.
Off—No Data.
ISDN B2
Table 1-39 LED Descriptions for the Cisco 897VAB-K9 ISR (continued)
Number LED Color Description

Cisco 897VA Specifications

General

Model	Cisco 897VA
Category	Network Router
Device Type	Router
Enclosure Type	Desktop
Connectivity Technology	Wired
USB Ports	1 x USB 2.0
Wireless	No
Memory	256 MB
RAM	256 MB
Flash Memory	128 MB
Power Device	Internal power supply
WAN Interfaces	1 x VDSL2/ADSL2+
Security	Firewall, VPN support
Routing Protocols	BGP, OSPF, EIGRP, RIP
Remote Management Protocol	SNMP, Telnet, SSH, HTTP, HTTPS
Features	Quality of Service (QoS), VLAN support, IPv6 support
Compliant Standards	IEEE 802.3, IEEE 802.3u
Interfaces	1 x USB
Voltage Required	100-240 VAC (50/60 Hz)
Operating Temperature	32 to 104 °F (0 to 40 °C)
Operating Humidity	10 to 85% (non-condensing)
