1-4 Introduction 4038501 Rev C
Power Supply, Continued
For Products Rated 24-65 VAC
The amplifier is delivered with a 24-65 VAC power supply for remote supply. The
correct voltage is labeled on the side of the amplifier.
The amplifier can be supplied with 24-65 VAC via coaxial cables (max. 7A), or
directly to the AC input (max. 15A).
Rating label for 24-65 VAC power supply
CAUTION:
Permanently exceeding the maximum remote current draw may result in
damage to the amplifier.
Fuses
Fuse 5 AT, for 100 - 240 VAC
Fuse 6.3 AT, for 24 - 65 VAC
Fuse 10A, for input/output port
Note: All fuses must be replaced by a similar type.
