Cisco ASA 5506W-X Installation Guide

Figure 2: ASA 5506H-X Package Contents
USB console cable (Type A to Type B)2Chassis1
Power cord4Power cord retention lock3
Power supply5
Front Panel
The following figure shows the front panel of the ASA 5506-X. The ASA 5506W-X has an identical front
panel. Note that there are no connectors or LEDs on the front panel.
Figure 3: 5506-X and 5506W-X Front Panel
The following figure shows the front panel of the ASA 5506H-X. Note that there are no connectors or LEDs
on the front panel.
Figure 4: 5506H-X Front Panel
Rear Panel
The following figure shows the rear panel of the ASA 5506-X. The 5506W-X has an identical rear panel.
