Cisco ASA 5516-X Hardware Installation Guide

CHAPTER 1
Overview
This chapter describes the hardware features of the Cisco ASA 5508-X and 5516-X, and contains the following
sections:
•
About the ASA 5508-X and 5516-X, page 1
•
Package Contents, page 2
•
Front Panel, page 3
•
Rear Panel, page 3
•
LEDs, page 4
•
Network Ports, page 6
•
Console Ports, page 6
•
Internal and External Flash Storage, page 6
•
Solid State Drive, page 7
•
Power Supply Modules, page 7
•
Hardware Specifications, page 7
•
Power Cord Specifications, page 8
About the ASA 5508-X and 5516-X
The Cisco ASA 5508-X and the ASA 5516-X adaptive security appliances are part of the ASA 5500-X of
next-generation mid-range ASAs, and are built on the same security platform as the rest of the ASA family.
Your ASA 5508-X and ASA 5516-X ship with either ASA or Firepower Threat Defense software
preinstalled. To reimage your device, see Reimage the Cisco ASA or Firepower Threat Defense Device.
Note
This next-generation ASA delivers unprecedented levels of defense against threats to the network with deeper
web inspection and flow-specific analysis, improved secure connectivity via end-point security posture
Cisco ASA 5508-X and ASA 5516-X Hardware Installation Guide
Online Only 1

Cisco ASA 5516-X Specifications

General

Firewall Throughput	1.8 Gbps
Concurrent Sessions	500, 000
Form Factor	1RU
Memory	8 GB
Flash Memory	8 GB
AC Input	100-240V AC
Maximum VLANs	1024
RAM	8 GB
Operating Temperature	32 to 104°F (0 to 40°C)
Storage Temperature	-13 to 158°F (-25 to 70°C)
Humidity	10 to 90% non-condensing
Power Supply	AC
Frequency	50 to 60 Hz
Interfaces	8 x 1Gbps (RJ-45), 8 x 1Gbps (SFP)
