Cisco ASA 5585-X

4-6
Cisco ASA 5585-X Adaptive Security Appliance Hardware Installation Guide
OL-22567-02
Chapter 4 Maintenance and Upgrade Procedures
Installing and Removing Cisco ASA 5585-X Network I/O Modules
Figure 4-2 shows the port numbering for the 4-port network I/O module.
Figure 4-2 4-Port Network I/O Module Port Numbering
Figure 4-3 shows the port numbering for the 8-port network I/O module.
Figure 4-3 8-Port Network I/O Module Port Numbering
1 TenGigabitEthernet 00 through 03
2
3
1
0
Cisco ASA 4-Port 10GE Network Module
STATUS
EJECT
PWR
1
332446
1 TenGigabitEthernet 00 through 07
2
3
1
0
6
7
5
4
STATUS
EJECT
PWR
Cisco ASA 8-Port 10GE Network Module
1
332447
