Step 3 Connect a USB 5-pin Mini USB Type B to the USB console port as shown in the following figure.
Figure 8: ASA 5506-X and ASA 5506W-X Console Port Connection
Mini USB Type B to USB Type
A console cable
2Mini USB Type B console port1
USB Type A3
Mount and Connect
9
Mount and Connect
Connect to the Console Port with Microsoft Windows
