Figure 53: Cisco ASR 9901 Router Front Panel Ports
External USB port6SYNC (BITS/J.211) ports1
10MHz and 1PPS ports7Service LAN and ToD
ports
2
Nine discrete LED
indicators
8CONSOLE and AUX
ports
3
LED matrix display9Management LAN ports4
Connectivity Management
Processor (CMP) port
5
Figure 54: Cisco ASR 9001 Router Front Panel Ports
External USB port6Service LAN and ToD
ports
1
Eight discrete LED
indicators
710MHz and 1PPS ports2
CLUSTER ports8SYNC (BITS/J.211) ports3
Fixed SFP+ ports9CONSOLE and AUX
ports
4
Management LAN ports5
Preparing for Installation
36
Preparing for Installation
Port Connection Guidelines

Cisco ASR 9901 Specifications

General

Chassis Height	1 RU
Rack Mounting	Yes
Redundancy	Yes
Operating System	Cisco IOS XR
Switching Capacity	Up to 1.2 Tbps
Memory	16 GB
Power Supply	Dual redundant AC or DC
Interfaces	10GE, 100GE
Operating Temperature	0 to 40°C (32 to 104°F)
Input Voltage	100-240V AC
Power Consumption	Varies based on configuration
Storage	64 GB SSD
Humidity	5% to 95% (non-condensing)
