Display Contents/LED Status and MeaningType of IndicatorComponent
INIT—Card is inserted and microcontroller is initialized
BOOT—Board is powered on and CPU is booting
IMEM—Start initializing memory
IGEN—Start initializing the board
ICBC—Start initializing communication with the microcontroller
SCPI—Board is not plugged in properly
STID—CBC was unable to read slot ID pins correctly
PSEQ—CBC detected power sequencer failure
DBPO—CBC detected an issue during board power up
KPWR—CBC detected an issue during board power up
LGNP—CBC detected an issue during board power up
LGNI—CBC detected an issue during board power up
RMN—All tests are finished and ROMMON is ready for commands
LOAD—Downloading MBI image to CPU
RRST—ROMMON is performing a soft reset after 5 consecutive MBI
validation requests timed out
MVB—ROMMON trying MBI validation boot
MBI—Starting execution of MBI
IOXR—Cisco IOS XR software is starting execution
LDG—The RP is loading (MBI started and card preparing for activity)
INCP—The software or configuration is incompatible with the RP
OOSM—The RP is in Out of Service, Maintenance mode
ACTV—RP role is determined to be active RP
STBY—RP role is determined to be standby RP
PREP—Preparing disk boot
Alphanumeric displayRP card
RP2 card
Green: The line card is enabled and ready for use.Status LEDLine Cards
Input power indicator on (green): Input AC power OK.
Output power indicator on (green): Output DC power OK.
Fault LED off (red): No fault is present. The correct power module voltages
are present and no faults have been detected.
Power status LEDsAC Power Modules
Cisco ASR 9000 Series Aggregation Services Router Hardware Installation Guide
202
Troubleshooting the Installation
Identifying Startup Issues
