Figure 203: Replacing the Cisco ASR 9906 Router Chassis Air Filter
• For the Cisco ASR 9006 Router and Cisco ASR 9904 Router, loosen the thumb screw that secures the
filter to the chassis, and then slide the air filter out of the chassis.
Figure 204: Replacing the Cisco ASR 9006 Router Chassis Air Filter
Thumb screw2Air filter1
Cisco ASR 9000 Series Aggregation Services Router Hardware Installation Guide
226
Replacing Cisco ASR 9000 Series Router Components
Replacing the Chassis Air Filter
