The DC power trays and power modules for the Cisco ASR 9000 Series Routers are identical, so the examples
shown in the below figures apply to all of these routers.
Note
To avoid shock hazard, be sure to apply shrink wrap tubing around the wire entry area of the lug.
Warning
Figure 51: Typical Source DC Power Cabling Scheme for a Single DC Power Module—Version 1 Power System
Cisco ASR 9000 Series Aggregation Services Router Hardware Installation Guide
41
Preparing for Installation
DC-Powered Router
