Cisco ASR 9912 Unpacking And Installing

Figure 47: Installing the Cisco ASR 9010 Router Chassis in a Seismic 2-Post Rack
Rear mounting bracket3Five screws per side
(minimum) to attach the
router chassis to the rack
1
Five screws to attach the
rear mounting bracket to
the router chassis
4Four screws (minimum)
to attach the rear
mounting bracket to the
rack
2
The figure below shows the orientation of the Cisco ASR 9006 Router chassis to the rack posts and components
used in the installation.
Unpacking and Installing the Chassis
51
Unpacking and Installing the Chassis
Installing the Chassis in a 2-Post Rack
