Table 1: ATA 191 Top Panel Items
DescriptionItem
Steady green: System booted up successfully and is ready for use.
Slow flashing green: System is booting up.
Fast flashing green three times, then repeats: System failed to boot
up.
Fast flashing green: The LED behaviour occurs in the following
situations:
• System detects a factory reset.
To perform a factory reset, press and hold the RESET button for
about 10 seconds.
• A factory reset is performed successfully.
Off: Power is off.
Power LED
Flashing green: Data transmission or reception is in progress through
the WAN port.
Off: No link.
Network LED
Steady green: On hook.
Slow flashing green: Off hook.
F ast flashing green threetimes, then repeats: The analog device failed
to register.
Fast flashing green: A factory reset is performed successfully.
Off: The port is not configured.
Phone 1 LED
Phone 2 LED
Press this button to create a problem report using the Problem Report
Tool.
This is not a power button. When you press this button, a
problem report is generated and uploaded to a server for the
system administrator.
Note
Problem Report Tool (PRT) Button
Flashing amber: The PRT is preparing the data for the problem report.
Fast Flashing amber: The PRT is sending the problem report log to
the PRT server.
Solid green for five seconds, then off: The PRT report was sent
successfully.
Fast flashing green: A factory reset is performed successfully.
Flashing red: The PRT report failed. Press the PRT button to turn the
LED off. Once it is off, another press triggers a new PRT report.
Problem Report Tool (PRT) LED
Cisco ATA 191 Analog Telephone Adapter Overview
5
Cisco ATA 191 Analog Telephone Adapter Overview
ATA 191 Top Panel
