Cisco C1000-8P-2G-L

Figure 6: Rear Panel of a PoE Switch
An AC power connector3Security Slot1
A loop (for the optional
power cord retainer)
4Heat sink fins2
Figure 7: Rear Panel of an Externally Powered Switch
A loop (for the optional
power cord retainer)
3Security Slot1
A DC power connector2
Cisco Catalyst 1000 Series 8-Port and 16-Port Switch Hardware Installation Guide
9
Product Overview
Rear Panel
