Cisco C3850-NM-4-1G User Manual

ActionInterface
Configure this interfaceTenGigabitEthernet1/1/7
Configure this interfaceTenGigabitEthernet1/1/8
C3850-NM-2-40G Module
The default port connections for the C3850-NM-2-40G module depends on whether you use a 40 G QSFP
module or a 4x10G breakout cable.
If you use a 40 G QSFP module, the ports default to 40 G interfaces. In this case, the 10 G interfaces are
displayed but not used.
Table 5: C3850-NM-2-40G Module with 40 G QSFP Module
ActionInterface
Configure this interfaceFortyGigabitEthernet1/1/1
Configure this interfaceFortyGigabitEthernet1/1/2
DisregardTenGigabitEthernet1/1/1
DisregardTenGigabitEthernet1/1/2
DisregardTenGigabitEthernet1/1/3
DisregardTenGigabitEthernet1/1/4
DisregardTenGigabitEthernet1/1/5
DisregardTenGigabitEthernet1/1/6
DisregardTenGigabitEthernet1/1/7
DisregardTenGigabitEthernet1/1/8
If you use a 4x10G breakout cable, the ports default to 10 G interfaces.
Table 6: C3850-NM-2-40G Module with 4x10G breakout cable
ActionInterface
DisregardFortyGigabitEthernet1/1/1
DisregardFortyGigabitEthernet1/1/2
Catalyst 3850 Switch Hardware Installation Guide
12 OL-26779-05
Installing a Network Module
Network Module Port Configurations
