Figure 5: C3850-NM-2-40G Network Module
LEDs3Captive screws1
40 G QSFP+ slots2
Figure 6: Blank Network Module
Captive screws2Blank module1
Catalyst 3850 Switch Hardware Installation Guide
OL-26779-05 5
