2-38
Cisco Integrated Services Router Hardware Installation Guide
Chapter 2 Installing the Router
Installing the Cisco 810 ISR
Figure 2-38 Installing Power Switch Lock
Figure 2-39 Power Switch Lock Installed
344033
1
2
3
4
5
1 Ring terminal 4 Power switch lock
2 Power switch lock washer 5 Pan-head screw
3 Power switch lock standoff
344034
