Cisco C9124AXE-E - C9124 Axe(Externalantenna)Model:antennaradiationpatterns

Figure 24: C9124AXD–AUX RF ASIC Antenna Radiation Pattern
(5–GHz Elevation)
Figure 23: C9124AXD–AUX RF ASIC Antenna Radiation Pattern
(5–GHz Azimuth)
C9124AXE(ExternalAntenna)Model:AntennaRadiationPatterns
The following illustrations show the C9124AXE model with external antenna radiation patterns:
Figure 26: AIR-ANT2413P2M-N: 2.4–GHz Dual-Polarized Two Port
Directional Antenna Pattern (Elevation)
Figure 25: AIR-ANT2413P2M-N: 2.4–GHz Dual-Polarized Two Port
Directional Antenna Radiation Pattern (Azimuth)
Cisco Catalyst 9124AX Series Outdoor Access Point Hardware Installation Guide
17
Hardware Features
C9124AXE (External Antenna) Model: Antenna Radiation Patterns
