Cisco C9130AXI Series User Manual

6
Cisco Catalyst 9130AX Series Access Points
The radio and antennas support frequency bands 2400–2500 MHz and 5150–5850 MHz through a common dual-band
RF interface. The C-ANT9101=, C-ANT9102=, and C-ANT9103= support frequency bands 2400–2500 MHz and
5150–7125 MHz.
Table 1 List of External Antennas Supported on C9130AXE
Part Number Description Gain
C-ANT9101= Ceiling Mount Omni Self-Identifying Antenna with
Bluetooth, 8-port, with DART connectors.
2 dBi (2.4 GHz)
6 dBi (5 GHz)
3 dBi (BLE)
C-ANT9102= Pole or Wall Mount Omni Self-Identifying Antenna
with Bluetooth, 8-port, with DART connectors.
4 dBi (2.4 GHz)
4 dBi (5 GHz)
4 dBi (BLE)
C-ANT9103= Pole or Wall mount 75° Directional Self-Identifying
Antenna with Bluetooth, 8-port, with DART
connectors.
6 dBi (2.4 GHz)
6 dBi (5 GHz)
6 dBi (BLE)
AIR-ANT2513P4M-N= Patch Antenna, 4-port, with N connectors.
Note Connect to AP using AIR-CAB003-D8-N =.
13 dBi (2.4 GHz)
13 dBi (5 GHz)
13 dBi (BLE)
AIR-ANT2524V4C-R= Ceiling Mount Omni Antenna, 4-port, with RP-TNC
connectors.
Note Connect to AP using AIR-CAB002-D8-R=.
2 dBi (2.4 GHz)
4 dBi (5 GHz)
AIR-ANT2524V4C-RS= Ceiling Mount Omni Self-Identifying Antenna, 4-port,
with RP-TNC connectors.
Note Connect to AP using AIR-CAB002-D8-R=.
2 dBi (2.4 GHz)
4 dBi (5 GHz)
AIR-ANT2544V4M-R= Wall Mount Omni Antenna, 4-port, with RP-TNC
connectors.
Note Connect to AP using AIR-CAB002-D8-R=.
4 dBi (2.4 GHz)
4 dBi (5 GHz)
AIR-ANT2544V4M-RS= Wall Mount Omni Self-Identifying Antenna, 4-port,
with RP-TNC connectors.
Note Connect to AP using AIR-CAB002-D8-R=.
4 dBi (2.4 GHz)
4 dBi (5 GHz)
AIR-ANT2566D4M-R= 60° Patch Antenna, 4-port, with RP-TNC connectors.
Note Connect to AP using AIR-CAB002-D8-R=.
6 dBi (2.4 GHz)
6 dBi (5 GHz)
AIR-ANT2566D4M-RS= 60° Patch Self-Identifying Antenna, 4-port, with
RP-TNC connectors.
Note Connect to AP using AIR-CAB002-D8-R=.
6 dBi (2.4 GHz)
6 dBi (5 GHz)

Cisco C9130AXI Series Specifications

General

Wi-Fi Standard	Wi-Fi 6 (802.11ax)
Antenna Type	Internal Antennas
Product Type	Wireless Access Point
Form Factor	Ceiling Mountable
Wireless Standard	802.11ax
Operating Temperature	0°C to 40°C (32°F to 104°F)
Mounting	Ceiling, Wall
USB Port	1 x USB 2.0
Frequency Bands	2.4 GHz, 5 GHz
Power Options	802.3at PoE+
Maximum Data Rate	4.8 Gbps
Weight	1.2 kg
MIMO Configuration	8x8:8 MU-MIMO (5 GHz), 4x4:4 MU-MIMO (2.4 GHz)
