Data Sheet
© 2009 Cisco Systems, Inc. All rights reserved. This document is Cisco Public Information. Page 10 of 21
QoS and Control
Advanced QoS
●
Standard 802.1p CoS and DSCP field classification are provided, using marking and
reclassification on a per-packet basis by source and destination IP address, source and
destination MAC address, or Layer 4 TCP or UDP port number.
●
Cisco control-plane and data-plane QoS ACLs on all ports help ensure proper marking on a
per-packet basis.
●
Four egress queues per port enable differentiated management of up to four traffic types.
●
SRR scheduling ensures differential prioritization of packet flows by intelligently servicing the
ingress and egress queues.
●
Weighted tail drop (WTD) provides congestion avoidance at the ingress and egress queues
before a disruption occurs.
●
Strict priority queuing guarantees that the highest-priority packets are serviced ahead of all
other traffic.
●
There is no performance penalty for highly granular QoS functions.
Granular Rate Limiting
●
The Cisco CIR function guarantees bandwidth in increments as small as 1 Mbps.
●
Rate limiting is provided based on source and destination IP address, source and destination
MAC address, Layer 4 TCP and UDP information, or any combination of these fields, using
QoS ACLs (IP ACLs or MAC ACLs), class maps, and policy maps.
●
Asynchronous data flows upstream and downstream from the end station or on the uplink are
easily managed using ingress policing and egress shaping.
●
Up to 64 aggregate or individual polices are available per Fast Ethernet or Gigabit Ethernet
port.
