Chapter 10
Server Load Balancing (SLB)
See the following sections to configure and use these features:
10-1: SLB: Covers the configuration steps needed to provide load balancing of traffic
to one or more server farms
10-2: SLB Firewall Load Balancing: Discusses the configuration steps necessary to
load balance traffic to one or more firewall farms
10-3: SLB Probes: Explains the configuration steps needed to define probes that test
server and firewall farm functionality
10-1: SLB
SLB provides a virtual server IP address to which clients can connect, representing a
group of real physical servers in a server farm. Figure 10-1 shows the basic SLB con-
cept. A client accesses a logical “virtual” server (IP address v.v.v.v), which exists only
within the Catalyst 6500 SLB configuration. A group of physical “real” servers (IP ad-
dresses x.x.x.x, y.y.y.y, and z.z.z.z) is configured as a server farm. Traffic flows be-
tween clients and the virtual server are load balanced across the set of real servers,
transparent to the clients.
As clients open new connections to the virtual server, SLB decides which real server
to use based on a load-balancing algorithm.
Server load balancing is performed by one of these methods:
Weighted round-robin: Each real server is assigned a weight that gives it the
capability to handle connections, relative to the other servers. For a weight n, a
server is assigned n new connections before SLB moves on to the next server.
Weighted least connections: SLB assigns new connections to the real server
with the least number of active connections. Each real server is assigned a

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Cisco Catalyst 4948 and is the answer not in the manual?

Cisco Catalyst 4948 Specifications

General IconGeneral
Switching Capacity136 Gbps
Forwarding Rate102 Mpps
Rack Units1U
MAC Address Table Size32, 000 entries
Authentication MethodRADIUS, TACACS+
RAM256 MB
Flash Memory64 MB
Power DeviceInternal power supply
Voltage Required100-240 VAC
Weight16.5 lbs
Operating Humidity10% to 85% non-condensing
Ports48 x 10/100/1000
Power SupplyInternal
Layer SupportLayer 3
Jumbo Frame SupportYes (up to 9216 bytes)
Routing ProtocolRIP, OSPF, EIGRP, BGP
Remote Management ProtocolSNMP, Telnet, SSH
FeaturesVLAN support, QoS
Compliant StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1Q, IEEE 802.1p
Operating Temperature32 °F to 104 °F (0 °C to 40 °C)
