Power supplies that are ordered are installed in the switch. If the second power supply is not ordered, a blank panel is installed.
Figure 3: Catalyst 6824-X-LE-40G
Ethernet management SFP port724 10G SFP+ ports or 100 MB or 1G SFP
fiber-optic ports
1
Two 40G QSFP+ uplink ports8Grounding pad2
Catalyst 6840-X Switch Series Hardware Installation Guide
6
Product Overview
Front Panel Components
