Cisco Catalyst 9130AX Series Access Points
Note When using the breakout cables and connecting to legacy dual band antennas, the BLE radio will experience
the gain of that antenna at 2.4 GHz.
AIR-ANT2524V4C-R= Ceiling Mount Omni Antenna, 4-port, with RP-TNC
connectors.
Note Connect to AP using AIR-CAB002-D8-R=.
2 dBi (2.4 GHz)
4 dBi (5 GHz)
AIR-ANT2524V4C-RS= Ceiling Mount Omni Self-Identifying Antenna, 4-port,
with RP-TNC connectors.
Note Connect to AP using AIR-CAB002-D8-R=.
2 dBi (2.4 GHz)
4 dBi (5 GHz)
AIR-ANT2544V4M-R= Wall Mount Omni Antenna, 4-port, with RP-TNC
connectors.
Note Connect to AP using AIR-CAB002-D8-R=.
4 dBi (2.4 GHz)
4 dBi (5 GHz)
AIR-ANT2544V4M-RS= Wall Mount Omni Self-Identifying Antenna, 4-port,
with RP-TNC connectors.
Note Connect to AP using AIR-CAB002-D8-R=.
4 dBi (2.4 GHz)
4 dBi (5 GHz)
AIR-ANT2566D4M-R= 60° Patch Antenna, 4-port, with RP-TNC connectors.
Note Connect to AP using AIR-CAB002-D8-R=.
6 dBi (2.4 GHz)
6 dBi (5 GHz)
AIR-ANT2566D4M-RS= 60° Patch Self-Identifying Antenna, 4-port, with
RP-TNC connectors.
Note Connect to AP using AIR-CAB002-D8-R=.
6 dBi (2.4 GHz)
6 dBi (5 GHz)
AIR-ANT2566P4W-R= Directional Antenna, 4-port, with RP-TNC
connectors.
Note Connect to AP using AIR-CAB002-D8-R=.
6 dBi (2.4 GHz)
6 dBi (5 GHz)
AIR-ANT2566P4W-RS= Directional Self-Identifying Antenna, 4-port, with
RP-TNC connectors.
Note Connect to AP using AIR-CAB002-D8-R=.
6 dBi (2.4 GHz)
6 dBi (5 GHz)
Table 5 List of External Antennas Supported on C9130AXE
Part Number Description Gain

Cisco Catalyst 9130AX Series Specifications

General

Wi-Fi Standard	Wi-Fi 6 (802.11ax)
Bluetooth	Bluetooth 5.0
Target Wake Time (TWT)	Yes
BSS Coloring	Yes
USB Port	1x USB 2.0
Frequency Bands	2.4 GHz, 5 GHz
PoE	802.3at (PoE+)
Antenna Type	Internal
OFDMA	Yes
Mounting	Ceiling, Wall
Weight	1.2 kg
Security	WPA3, WPA2, WPA, 802.1X
Management	Cisco DNA Center, Cisco Prime Infrastructure
MIMO	8x8:8 MU-MIMO (5 GHz), 4x4:4 MU-MIMO (2.4 GHz)
