Cisco Catalyst 9130AX Series Access Points
Warning This product relies on the building’s installation for short-circuit (overcurrent) protection. Ensure that
the protective device is rated not greater than 20A. Statement 1005
Warning Installation of the equipment must comply w ith local and national electrical codes. Statement 1074
Warning In order to comply w ith FCC radio frequency (RF) exposure limits, antennas should be located at a
minimum of 12 inches (30 cm) or more from the body of all persons. Statement 332
Warning Ultimate disposal of this product should be handled according to all national law s and regulations.
Statement 1040
Warning This equipment is suitable for use in environment air spaces (plenums) in accordance w ith Section
300.22 (C) of the National Electrical Code, and Sections 2-128, 12-010(3) and 12-100 of the Canadian
Electrical Code, Part 1, CSA C22.2. External pow er supply, pow er adapter and/or pow er injector, if
provided, are not suitable for installation in air spaces. Statement 440
4 Unpacking
To unpack the access point, follow these steps:
Step 1 Unpack and remove the access point and the accessory kit from the shipping box.
Step 2 Return any packing material to the shipping container and save it for future use.
Step 3 Verify that you have received the items listed below. If any item is missing or damaged, contact your Cisco
representative or reseller for instructions.
— The access point
— (Optional) Mounting bracket (AIR-AP-BRACKET-1= (default) or AIR-AP-BRACKET-2=, only if selected when
you order the access point)
— Adjustable ceiling-rail clip (AIR-AP-T-RAIL-R or AIR-AP-T-RAIL-F) (selected when you order the access point)
The following accessories can be ordered separately from Cisco:
• Antenna bracket AIR-AP-BRACKET-9= to mount the C9130AXE directly to the back of the C-ANT9103=
antenna
• AIR-AP-BRACKET-1= for ceiling mount installations
• AIR-AP-BRACKET-2= for wall or electrical box installations
• Mid-span power injector AIR-PWRINJ6= when PoE is not available

Cisco Catalyst 9130AX Series Specifications

General

Wi-Fi Standard	Wi-Fi 6 (802.11ax)
Bluetooth	Bluetooth 5.0
Target Wake Time (TWT)	Yes
BSS Coloring	Yes
USB Port	1x USB 2.0
Frequency Bands	2.4 GHz, 5 GHz
PoE	802.3at (PoE+)
Antenna Type	Internal
OFDMA	Yes
Mounting	Ceiling, Wall
Weight	1.2 kg
Security	WPA3, WPA2, WPA, 802.1X
Management	Cisco DNA Center, Cisco Prime Infrastructure
MIMO	8x8:8 MU-MIMO (5 GHz), 4x4:4 MU-MIMO (2.4 GHz)
