Cisco Catalyst 9136I Series - 5 AP Views, Ports, and Connectors

7
Cisco Catalyst 9136I Series Access Points
• AIR-AP-BRACKET-1= for low profile installations
• AIR-AP-BRACKET-2= for electrical or network boxes, above ceiling mounts
• Mid-span power injector AIR-PWRINJ7= when PoE is not available
5 AP Views, Ports, and Connectors
Figure 1 Face of the 9136AXI Model
1
Status LED
3
USB 2.0 port
2
Location of the ports and connectors on the head of the
AP.
