WeightSwitch Model
10 lb (4.53 kg)C9200L-48T-4X
10.6 lb (4.8 kg)C9200L-48P-4X
10.4 lb (4.71 kg)C9200L-24P-4X
9.6 lb (4.35 kg)C9200L-24T-4X
10.6 lb (4.8 kg)C9200L-48PL-4G
10.6 lb (4.8 kg)C9200L-48PL-4X
12 lb (5.44 kg)C9200L-24PXG-4X
12 lb (5.44 kg)C9200L-24PXG-2Y
12.6 lb (5.71 kg)C9200L-48PXG-4X
12.6 lb (5.71 kg)C9200L-48PXG-2Y
This table describes the physical specifications.
Table 19: Physical Specifications for the Power Supplies
Weight
1.5 lb (0.68 kg)
PWR-C5-125WAC
1.7 lb (0.77 kg)PWR-C5-600WAC
2 lb (0.9 kg)PWR-C5-1KWAC
1.5 lb (0.68 kg)PWR-C6-125WAC
1.7 lb (0.77 kg)PWR-C6-600WAC
2 lb (0.9 kg)PWR-C6-1KWAC
Dimensions (H x D x W)
The dimensions shown include the extraction handle and the keying feature.
1.58 x 4.0 x 7.6 in. (40.1 X 101.6 X 193 mm)
PWR-C5-125WAC
PWR-C5-600WAC
PWR-C5-1KWAC
PWR-C6-125WAC
PWR-C6-600WAC
PWR-C6-1KWAC
Cisco Catalyst 9200 Series Switches Hardware Installation Guide
76
Technical Specifications
Technical Specifications
