Cisco Catalyst C9300-24U User Manual

CONTENTS
Preface ix
PREFACE
Document Conventions ix
Related Documentation xi
Obtaining Documentation and Submitting a Service Request xi
Product Overview 1
CHAPTER 1
Switch Models 2
Front Panel Components 4
10/100/1000 Ports 11
PoE, PoE+, Cisco UPOE and Cisco UPOE+ Ports 11
Multigigabit Ethernet Ports 11
Management Ports 12
USB Type A and Type C Ports 13
Uplink Ports 13
LEDs 14
USB Console LED 15
System LED 15
Active LED 15
STACK LED 16
PoE LED 17
XPS LED 17
S-PWR LED 17
Port LEDs and Modes 18
Beacon LED 20
Network Module LEDs 21
Cisco Catalyst 9300 Series Switches Hardware Installation Guide
ii
Contents

Cisco Catalyst C9300-24U Specifications

General

Model	C9300-24U
Device Type	Switch
Enclosure Type	Rack-mountable
DRAM	8 GB
Flash	16 GB
Stacking Bandwidth	480 Gbps
Max Stacking Number	8
PoE Budget	1440W
MAC Address Table Size	32, 000 entries
Power Redundancy	Yes
Uplink Interfaces	4 x 10G SFP+
Routing Protocol	OSPF, EIGRP, BGP, IS-IS, RIP
Remote Management Protocol	SNMP, CLI, HTTP, HTTPS, SSH, Telnet
Features	Quality of Service (QoS), Access Control List (ACL), VLAN
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad, IEEE 802.1x
Dimensions	17.5 in x 17.5 in x 1.7 in
Operating Temperature	0 to 45°C
Ports	24 x 10/100/1000 (UPOE)
Weight	14.99 lbs
