Table 6: LED Descriptions
LED StatusDescriptionLED
Number
Off: Ignition power management is disabled when SYS LED is on.
Steady Green combined with SYS LED Off: Ignition signal is off
(power management is enabled).
Steady Green combined with SYS LED On: Ignition signal is on.
Flashing Green with Ignition Off: Timer counts down when SYS LED
is on.
Steady Yellow: Ignition power management feature is not loaded.
Ignition Status1
Steady Green: Operational.
Flashing Green: Cisco IOS-XE booting.
Steady Yellow: System in ROMMON mode.
Off: No power.
System Status2
Off: Inactive.
Steady Yellow: Active.
Digital I/O3 and 4
Steady Green: GPS/DR configured; location fix achieved.
Flashing Green: GPS DR active; trying to achieve location fix.
Off: GPS DR not configured.
GPS Module5
Steady Green: SSD is being accessed.
Off: No power or is not enabled.
SSD Module6
Steady Green: Port is up with link.
Flashing Green: Link with activity.
Off: Port is off or down.
Four Gigabit Ethernet LAN ports labeled 1/0,
1/1, 1/2, 1/3
See the IR1800 Software
Configuration Guide for Cisco
IOS-XE naming conventions.
Note
7
Steady Green: POE or POE+ power supplied on one LAN Port.
Off: No POE or POE+ power in any LAN port.
PoE Power Status8
Steady Green: Port is up with link.
Flashing Green: Link with activity.
Off: No link, or port is off.
RJ45 Gigabit Ethernet WAN
Either the SFP or the RJ45 LED will
be On, depending on what type of
interface is used in the combo port.
Note
9
Steady Green: Port is up with link.
Flashing Green: Link with activity.
Off: No link, or port is off.
SFP Gigabit Ethernet WAN
Either the SFP or the RJ45 LED will
be On, depending on what type of
interface is used in the combo port.
Note
10
Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
18
Product Overview
Front Panel LEDs
