Connecting to a Home Theater System with
Component (YPbPr) Connectors
Cables Used in this Confi guration
• 3 Sets Component Video Cables (YPbPr)
• 2 Sets Audio Left/Right Cables (you can also use optical cables instead of the
Audio Left/Right Cables as shown in the diagram, indicated by dotted lines)
• 1 RCA-type Video Cable
Note: This connection assumes that audio is provided by the home theater speakers.
