1-4
Cisco 850 Series and Cisco 870 Series Access Routers Hardware Installation Guide
OL-5331-01
Chapter 1 Product Overview
General Descriptions of the Router Models
Figure 1-5 Cisco 857 Router Back Panel, with Antenna Installed
Figure 1-6 Cisco 877 Router Back Panel, with Antennas Installed
ADSLoPOTS
LAN
FE0
FE1
FE2
FE3
Cisco 857W
CONSOLE
AUX
RESET
+5,+12 VDC
122242
SN: XXXNNNNXXXX
ADSLoPOTS
LAN
FE0
FE1
FE2
FE3
Cisco 877W
CONSOLE
AUX
RESET
+5,+12 VDC
127093
SN: XXXNNNNXXXX
LEFT
RIGHT/PRIMARY
