4-3
Cisco 850 Series and Cisco 870 Series Access Routers Hardware Installation Guide
OL-5331-01
Chapter 4 Router Cabling Procedures
Typical Installations
Figure 4-1 Typical Installation of a Cisco 851 or Cisco 871 Router
1 Ethernet connection to an external switch 4 Console port
2 Ethernet connection to a PC 5 Power adapter
3 WAN connection using a broadband modem to the
Internet
LAN
4
3
2
1
Cisco 871W
CONSOLE
AUX
RESET
+5,+12 VDC
LEFT
RIGHT / PRIMARY
1
0
WAN
FE4
FE0
FE1
FE2
FE3
1
X
2
X
1
X
2
X
1
InternetInternet
1 2 5
3
4
122237
SN: XXXNNNNXXXX
