DETAILED STEPS
Step 1
Ensure that the unistruts are installed. See the Steps, on page 4.
Step 2
Attach the rear vertical cable troughs —one right and one left—to the rear of the chassis (as shown in the figure below)
by i nserting the 10 M4x14-mm flat head screws (5 on each side) and using the screwdriver to fasten the screws to attach
the cable troughs firmly to the chassis.
We recommend that you use two people to install the troughs, one person to hold the troughs in place while the
other person inserts and tightens the screws.
Note
Cisco CRS Carrier Routing System Fabric Card Chassis Installation Guide
27
Installing and Removing Exterior Cosmetic Components
Steps

Cisco CRS Specifications

General

Operating System	Cisco IOS XR
Product Type	Core Router
Form Factor	Modular Chassis
Dimensions	Varies by chassis type
Weight	Varies by chassis type
Architecture	Distributed
Switch Fabric	Multi-stage
Interface Support	Ethernet, SONET/SDH, OTN
Interfaces/Ports	Varies by line card
Port Density	Varies by line card
Routing Protocol	BGP, IS-IS, OSPF, MPLS
Management	CLI, SNMP
Power Supply	Redundant, hot-swappable
Cooling	Redundant, Hot-swappable Fan Trays
Supported Protocols	IPv4, IPv6, MPLS
Management Interfaces	Ethernet, console
Security Features	ACLs
