I/O Modules for the Cisco CSS 11500 Content Services Switch
The Cisco CSS 11500 I/O modules deliver port density and flow performance. The product line supports three types
of I/O modules:
• Two-port Gigabit Ethernet
• Sixteen-port Fast Ethernet
• Eight-port Fast Ethernet
The Fast Ethernet ports are 10/100BASE-TX with standard RJ-45 connectors, whereas the Gigabit Ethernet ports
require small-form factor GBICs (1000BASE-SX or 1000BASE-LX).
Session Accelerator Module for the Cisco CSS 11500 Content Services Switch
The session accelerator module is a cost-effective way to add flow performance when additional connectivity is not
required. Using the same flow setup and forwarding processors as the I/O modules, it provides the flexibility to
optimize the system for port density and performance. Table 1 gives the features of the Cisco CSS 11500 models.
1
Virtual Internet Protocol (Address)
Ta b le 1 Cisco CSS 11500 Models: Quick Look
Cisco CSS 11503 Cisco CSS 11506
Number of modular slots 36
Included in base configuration Switch Control Module
2 Gigabit Ethernet (GBIC) ports
Switch Control Module
2 Gigabit Ethernet (GBIC) ports
Maximum Gigabit Ethernet ports 612
Maximum 10/100 Ethernet ports 32 80
2-port Gigabit Ethernet I/O Module Maximum of 2 Maximum of 5
16-port 10/100 Ethernet I/O Module Maximum of 2 Maximum of 5
8-port 10/100 Ethernet I/O Module Maximum of 2 Maximum of 5
SSL modules Maximum of 2 Maximum of 5
Session accelerator modules Maximum of 2 Maximum of 5
Redundancy features Active-active Layer 5
Adaptive Session Redundancy
VIP
1
redundancy
Active-active Layer 5
Adaptive Session Redundancy
VIP redundancy
Active-standby SCM
Redundant switch fabric module
Redundant power supplies
Height 3.5” (2 rack units) 8.75” (5 rack units)
Bandwidth Aggregate 20 Gbps Aggregate 40 Gbps
Storage 512-MB hard disk or
256-MB Flash memory disk
512-MB hard disk or
256-MB Flash memory disk
Power Integrated AC or DC Up to 3 AC or 3 DC
