7-17
Cisco uBR7100 Series Universal Broadband Router
Chapter 7 Broadband and Dial Access Products
CHAPTER 7 BROADBAND AND
DIAL ACCESS PRODUCTS
• Standards-based: DOCSIS and EuroDOCSIS models available
• Reliable operation to ensure the system remains online
• Uses Cisco IOS software
Specifications
For More Information
See the Cisco uBR7100 series Web site: http://www.cisco.com/go/ubr7100
Feature Cisco uBR7111 and uBR7114 Cisco uBR7111E and uBR7114E
Embedded Processor
MIPS RISC527/RM7000, 75 MHz Bus MIPS RISC527/RM7000, 75 MHz Bus
Throughput of Services
50 Mbps 50 Mbps
Memory
Flash: 48 MB; Packet: 64 MB; System: 128 MB
System memory expandable to 256 MB
Flash: 48 MB; Packet: 64 MB; System: 128 MB
System memory expandable to 256 MB
Line Card with Integrated
Upconverter (Cable Plant
Interface)
uBR7111: 1 downstream and 1 upstream
uBR7114: 2 downstream and 4 upstreams
uBR7111E: 1 downstream and 1 upstream
uBR7114E: 2 downstream and 4 upstreams
Integrated Upconverter
DOCSIS Annex B, 6 MHz
High level output: =+61dBmV, 55 to 858 MHz
Optimized for 64 and 256 QAM
DOCSIS Annex A, 8 MHz,
High level output: = +61 dBmV, 55 to 858 MHz
Optimized for 64 and 256 QAM
Port Adapter (WAN or
backbone Interface)
Embedded dual 10/100 BaseT Ethernet (TX FE) provided
Supports one additional PA; options include the following
using Cisco IOS Release12.1(8)EC minimum:
Ethernet:
• PA-4E-4-port Ethernet 10BASE-T
Fast Ethernet:
• PA-FE-TX-1-port 100BASE-TX Fast Ethernet
• PA-FE-FX-1-port 100BASE-FX Fast Ethernet
• PA-2FE-TX 2-port 100BASE-TX Fast Ethernet
• PA-2FE-FX 2-port 100BASE-FX Fast Ethernet
Serial:
• PA-MC-4T1 4-port multichannel T1 Port Adapter with
integrated CSU/DSUs
• PA-MC-2T1 2-port multichannel T1 Port Adapter with
integrated CSU/DSUs
• PA-E3-1-port E3 serial Port Adapter with E3 DSU
• PA-T3-1-port T3 serial Port Adapter with T3 DSU
• PA-2E3-2-port E3 serial Port Adapter with E3 DSUs
• PA-2T3-2-port T3 serial Port Adapter with T3 DSUs
• PA-4T+-4-port serial Port Adapter, enhanced
• PA-4E1G-75-4-port E1-G.703 serial Port Adapter
(75-ohm/unbalanced)
• PA-4E1G-120-4-port E1-G.703 serial Port Adapter
(120-ohm/balanced)
• PA-8T-V35-8-port serial V.35 Port Adapter
HSSI:
• PA-2H-2-port HSSI
ATM:
• PA-A3-8T1IMA, 8-port ATM inverse T1 multiplexer Port
Adapter
• PA-A3-OC3MM, 1-port ATM enhanced OC3c/STM1
multimode Port Adapter
POS:
• PA-POS-OC3SMI, 1-port Packet/SONET OC3c/STM1
single-mode Port Adapter
Same as Cisco uBR7111 and Cisco uBR7114
Power Options
Single; 100 to 240 VAC input voltage Single; 100 to 240 VAC input voltage
Minimum Cisco IOS
release
12.1(5)ECI minimum 12.1(7)EC minimum
