4024320 Rev A 107
Front Panel LED Status Indicator Functions
Normal Operations (AC Power applied)
The following chart illustrates the appearance of the residential gateway front panel
LED status indicators during normal operations when AC power is applied to the
gateway.
Front Panel LED Status Indicators During Normal Conditions
Front Panel Indicator Normal Operations
1 POWER On
2 DS On
3 US On
4 ONLINE On
5 LAN1-LAN4
On - When a single device is connected to the Ethernet port and
no data is being sent to or from the modem
Blinks - When only one Ethernet device is connected and data is
being transferred between the consumer premise equipment
(CPE) and the wireless home gateway
Off - When no devices are connected to the Ethernet ports
6 WIRELESS
On - When the wireless access point is enabled and operational
Blinks - When data is being transferred between the CPE and
the wireless home gateway
Off - When the wireless access point is disabled by the user
