Cisco Firepower 1120 Getting Started

• Enter the IPv4 default gateway for the management interface—If you set a manual IP address, enter
either data-interfaces or the IP address of the gateway router. The data-interfaces setting sends outbound
management traffic over the backplane to exit a data interface. This setting is useful if you do not have
a separate Management network that can access the internet. Traffic originating on the Management
interface includes license registration and database updates that require internet access. If you use
data-interfaces, you can still use the FDM (or SSH) on the Management interface if you are
directly-connected to the Management network, but for remote management for specific networks or
hosts, you should add a static route using the configure network static-routes command. Note that the
FDM management on data interfaces is not affected by this setting. If you use DHCP, the system uses
the gateway provided by DHCP and uses the data-interfaces as a fallback method if DHCP doesn't
provide a gateway.
• If your networking information has changed, you will need to reconnect—If you are connected with
SSH to the default IP address but you change the IP address at initial setup, you will be disconnected.
Reconnect with the new IP address and password. Console connections are not affected.
• Manage the device locally?—Enter yes to use the FDM. A no answer means you intend to use the FMC
to manage the device.
Example:
You must accept the EULA to continue.
Press <ENTER> to display the EULA:
End User License Agreement
[...]
Please enter 'YES' or press <ENTER> to AGREE to the EULA:
System initialization in progress. Please stand by.
You must change the password for 'admin' to continue.
Enter new password: ********
Confirm new password: ********
You must configure the network to continue.
You must configure at least one of IPv4 or IPv6.
Do you want to configure IPv4? (y/n) [y]:
Do you want to configure IPv6? (y/n) [n]:
Configure IPv4 via DHCP or manually? (dhcp/manual) [manual]:
Enter an IPv4 address for the management interface [192.168.45.45]: 10.10.10.15
Enter an IPv4 netmask for the management interface [255.255.255.0]: 255.255.255.192
Enter the IPv4 default gateway for the management interface [data-interfaces]: 10.10.10.1
Enter a fully qualified hostname for this system [firepower]: ftd-1.cisco.com
Enter a comma-separated list of DNS servers or 'none' [208.67.222.222,208.67.220.220]:
Enter a comma-separated list of search domains or 'none' []:
If your networking information has changed, you will need to reconnect.
For HTTP Proxy configuration, run 'configure network http-proxy'
Manage the device locally? (yes/no) [yes]: yes
>
Step 4 Log into the FDM on the new Management IP address.
Getting Started
22
Getting Started
(Optional) Change Management Network Settings at the CLI

Cisco Firepower 1120 Specifications

General

Processor cores	12
Processor family	Intel
Built-in processor	Yes
Firewall throughput	1500 Mbit/s
Wi-Fi	No
IPSec VPN throughput	1 Gbit/s
Maximum firewall connections	200000
Maximum firewall connections per second	75000
Supported network protocols	SMTP
Console port	RJ-45
Connectivity technology	Wired
Number of console ports	1
SFP module slots quantity	4
Ethernet LAN (RJ-45) ports	8
SSD capacity	200 GB
Storage media type	SSD
Form factor	1U
Input current	2 A
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	100 W
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Country of origin	Mexico
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990
Package depth	1409.7 mm
Package width	990.6 mm
Package height	457.2 mm
Package weight	5782.31 g

Weight and Dimensions

Depth	436.9 mm
Width	268.7 mm
Height	43.7 mm
