Cisco Firepower 1120 Getting Started

You must complete these steps to continue.
Step 3 Configure the following options for the outside and management interfaces and click Next.
Your settings are deployed to the device when you click Next. The interface will be named
“outside” and it will be added to the “outside_zone” security zone. Ensure that your settings are
correct.
Caution
Outside Interface
• Configure IPv4—The IPv4 address for the outside interface. You can use DHCP or manually enter a
static IP address, subnet mask, and gateway. You can also select Off to not configure an IPv4 address.
Do not configure an IP address on the same subnet as the default inside address (see Default Configuration
Prior to Initial Setup, on page 26), either statically or through DHCP. You cannot configure PPPoE using
the setup wizard. PPPoE may be required if the interface is connected to a DSL modem, cable modem,
or other connection to your ISP, and your ISP uses PPPoE to provide your IP address. You can configure
PPPoE after you complete the wizard. See Configure a Physical Interface.
• Configure IPv6—The IPv6 address for the outside interface. You can use DHCP or manually enter a
static IP address, prefix, and gateway. You can also select Off to not configure an IPv6 address.
Management Interface
• DNS Servers—The DNS server for the system's management address. Enter one or more addresses of
DNS servers for name resolution. The default is the OpenDNS public DNS servers, or the DNS servers
you obtain from the DHCP server. If you edit the fields and want to return to the default, click Use
OpenDNS to reload the appropriate IP addresses into the fields. Your ISP might require that you use
specific DNS servers. If after completing the wizard, you find that DNS resolution is not working, see
Troubleshooting DNS for the Management Interface.
• Firewall Hostname—The hostname for the system's management address.
Step 4 Configure the system time settings and click Next.
• Time Zone—Select the time zone for the system.
• NTP Time Server—Select whether to use the default NTP servers or to manually enter the addresses
of your NTP servers. You can add multiple servers to provide backups.
Step 5 Configure the smart licenses for the system.
You must have a smart license account to obtain and apply the licenses that the system requires. Initially, you
can use the 90-day evaluation license and set up smart licensing later.
To register the device now, select the option to register the device, click the link to log into your Smart Software
Manager account, generate a new token, and copy the token into the edit box. You must also select your
services region, and decide whether to send usage data to the Cisco Success Network. The on-screen text
explains these settings in more detail.
If you do not want to register the device yet, select the evaluation mode option. The evaluation period last up
to 90 days. To later register the device and obtain smart licenses, click Device, then click the link in the Smart
Licenses group.
Step 6 Click Finish.
Getting Started
24
Getting Started
Complete the Initial Configuration Using the Setup Wizard

Cisco Firepower 1120 Specifications

General

Processor cores	12
Processor family	Intel
Built-in processor	Yes
Firewall throughput	1500 Mbit/s
Wi-Fi	No
IPSec VPN throughput	1 Gbit/s
Maximum firewall connections	200000
Maximum firewall connections per second	75000
Supported network protocols	SMTP
Console port	RJ-45
Connectivity technology	Wired
Number of console ports	1
SFP module slots quantity	4
Ethernet LAN (RJ-45) ports	8
SSD capacity	200 GB
Storage media type	SSD
Form factor	1U
Input current	2 A
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	100 W
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Country of origin	Mexico
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990
Package depth	1409.7 mm
Package width	990.6 mm
Package height	457.2 mm
Package weight	5782.31 g

Weight and Dimensions

Depth	436.9 mm
Width	268.7 mm
Height	43.7 mm
