Cisco Firepower 1120 User Manual

connect a new Firepower 1100 to a network so that the IT department can on board the device to CDO and
configure it remotely. CDO supports Firepower Threat Defense (FTD) version 6.7 and later.
The following figure shows the QR code sticker.
Figure 3: QR Code Sticker
The following figure shows the placement of the QR code sticker on the rear panel of the chassis.
Figure 4: QR Code Sticker on the Chassis
—QR code sticker1
Serial Number Location
You can view the serial number and additional model information on the compliance label located on the
bottom of the chassis. The following figure shows a sample compliance label.
Cisco Firepower 1100 Series Hardware Installation Guide
7
Overview
Serial Number Location

Cisco Firepower 1120 Specifications

General

Processor cores	12
Processor family	Intel
Built-in processor	Yes
Firewall throughput	1500 Mbit/s
Wi-Fi	No
IPSec VPN throughput	1 Gbit/s
Maximum firewall connections	200000
Maximum firewall connections per second	75000
Supported network protocols	SMTP
Console port	RJ-45
Connectivity technology	Wired
Number of console ports	1
SFP module slots quantity	4
Ethernet LAN (RJ-45) ports	8
SSD capacity	200 GB
Storage media type	SSD
Form factor	1U
Input current	2 A
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	100 W
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Country of origin	Mexico
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990
Package depth	1409.7 mm
Package width	990.6 mm
Package height	457.2 mm
Package weight	5782.31 g

Weight and Dimensions

Depth	436.9 mm
Width	268.7 mm
Height	43.7 mm
