Cisco Firepower 1140 Deployment Guide

Figure 2: Firepower 1100 Cabling
Figure 3: Firepower 2100 Cabling
6. Observe the Stauts/SYS LED light pattern on the device to determine if the device has reached the Cisco
cloud. The table below provides the LED light patterns and the approximate time they occur. It may take
a little more time or a little less time for the Firepower device to reach the Cisco cloud based on network
conditions and the Firepower model you are working with.
Time this ocurs after the
device is powered on.
(minutes:seconds)
DescriptionLight pattern of Stauts/SYS LED
01:00The device is booting up
correctly.
Fast flashing green
01:00The device failed to boot
correctly.
Fast flashing amber
10:00The application is loaded on the
device.
Solid green
Firepower Easy Deployment Guide for Cisco Firepower 1000 or 2100 Firewalls
3
Firepower Easy Deployment Guide for Cisco Firepower 1000 or 2100 Firewalls
Connect a New Cisco Firepower Firewall to Your Network

Cisco Firepower 1140 Specifications

General

Processor cores	16
Processor family	Intel
Built-in processor	Yes
Firewall throughput	2200 Mbit/s
IPSec VPN throughput	1.2 Gbit/s
Maximum firewall connections	400000
Maximum firewall connections per second	100000
Wi-Fi	No
Supported network protocols	SMTP
Console port	RJ-45
Connectivity technology	Wired
SFP module slots quantity	4
Ethernet LAN (RJ-45) ports	8
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
SSD capacity	200 GB
Storage media type	SSD
Form factor	1U
Input current	2 A
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	100 W
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Country of origin	Mexico
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990
Package depth	1409.7 mm
Package width	990.6 mm
Package height	457.2 mm
Package weight	5782.31 g

Weight and Dimensions

Depth	436.9 mm
Width	268.7 mm
Height	43.7 mm
