Cisco Firepower 2130

Figure 33: Attach the Rack-Mount Bracket to the Side of the Chassis
Rack-mount bracket2Chassis1
8-32 x 0.25-in. countersink Phillip head screws
(3 per side)
3
Step 2 (Optional) Attach the cable management bracket to the rack-mount bracket:
a) Install the cable management studs into the rack-mount bracket.
Cisco Firepower 2100 Series Hardware Installation Guide
47
Mount and Connect
Rack-Mount the Chassis
