Cisco Firepower 2130 User Manual

Figure 1: Attach the Rack-Mount Bracket to the Side of the Chassis
Rack-mount bracket2Chassis1
8-32 x 0.281-inch Phillips screws (three per side)3
Step 2 (Optional) Attach the cable management bracket to the rack-mount bracket:
a) Install the cable management screws into the rack-mount bracket.
Figure 2: Install the Cable Management Screws into the Rack-Mount Bracket
b) Install two 8-32 x 0.375-inch screws through the inside of each rack-mount bracket to secure the cable management
bracket to the rack-mount bracket.
Rack-Mount and Ground the Chassis
3
Rack-Mount and Ground the Chassis
Rack-Mount the Chassis Using Brackets

Cisco Firepower 2130 Specifications

General

Form Factor	1 RU
Firewall Throughput (Application Visibility and Control AVC)	4 Gbps
RAM	16 GB
Storage	120 GB SSD
Interfaces	8 x 1GE
Power Supply	Dual, Hot-swappable
