Figure 4: Firepower 2100 DC Power Supply Module
FAIL and OK LEDs2Handle1
Ejector latch4DC power connector3
Safety Warnings
Take note of the following warnings:
Statement 1003—DC Power Disconnection
To reduce risk of electric shock or personal injury, disconnect DC power before removing or replacing
components or performing upgrades.
Warning
Statement 1005—Circuit Breaker
This product relies on the building’s installation for short-circuit (overcurrent) protection. To reduce risk
of electric shock or fire, ensure that the protective device is rated not greater than:
AC: 20A
DC: 40A
Warning
Installation, Maintenance, and Upgrade
10
Installation, Maintenance, and Upgrade
Connect the DC Power Supply Module
