Cisco Firepower 2140

Figure 3: Attach the Slide-Rail Locking Bracket to the Side of the Chassis
Slide-rail locking bracket2Chassis1
—8-32 x 0.25-inch Phillips screws (three per side)3
Step 2 (Optional) Attach the cable management bracket to the slide-rail locking bracket:
a) Install the cable management screws into the slide-rail locking bracket.
Figure 4: Install the Cable Management Screws into the Slide-Rail Locking Bracket
b) Install two 8-32 x 0.375-inch Phillips screws through the inside of the slide-rail locking bracket to secure the cable
management bracket to slide-rail locking bracket.
Rack-Mount and Ground the Chassis
6
Rack-Mount and Ground the Chassis
Rack-Mount the Chassis Using Slide Rails
