Specifications.
Linksys E2500.
Environmental
Linksys E2500
Dimensions. 225 x 35 x 180 mm
Model Name. Linksys E2500.
(8.86” x 1.38” x 7.09”).
Description. Advanced Dual-Band N Router.
Model Number. E2500.
Standards. 802.11n, 802.11a, 802.11g, 802.11b, 802.3,
802.3u, 802.3ab.
# of Antennas. 4 total, 2 internal antennas per each
2.4 GHz & 5 GHz radio band.
Detachable (y/n). No.
Modulation. 802.11b: CCK, QPSK, BPSK
802.11g: OFDM.
802.11a: OFDM.
802.11n: BPSK, QPSK, 16-QAM,
64-QAM.
Receive Sensitivity.
(Typical).
2.4 GHz.
802.11b: -87 dBm @ 11 Mbps.
802.11g: -70 dBm @ 54 Mbps
802.11n 20 MHz: -70 dBm @ MCS15.
802.11n 40 MHz: -66 dBm @ MCS15.
5 GHz.
802.11a: -70 dBm @ 54 Mbps.
802.11n 20 MHz: -66 dBm @ MCS23.
802.11n 40 MHz: -62 dBm @ MCS23.
Antenna Gain in dBi. 2.4 GHz:.
Antenna 1 (right rear): ≤2.94 dBi.
Antenna 2 (front right): ≤3.78 dBi.
5 GHz:.
Antenna 1 (right front): ≤5.86 dBi.
Antenna 2 (front left): ≤4.88 dBi.
UPnP. Supported.
Security features. WEP, WPA, WPA2.
Security key bits. Up to 128-bit encryption.
Unit Weight. 452 g (15.94 oz).
Power. 12V, 1A.
Certifications. FCC, IC, CE, Wi-Fi A/B/G/N
Operating Temp. 0 to 40°C (32 to 104°F).
Storage Temp. -20 to 60°C (-4 to 140°F)
Operating Humidity. 10 to 80%, relative humidity,
non-condensing.
Storage Humidity. 5 to 90% non-condensing.
NOTES
For regulatory, warranty, and safety information, see the CD that
came with your router or go to Linksys.com/support
Specifications are subject to change without notice.
Maximum performance derived from IEEE Standard 802.11
specifications Actual performance can vary, including lower
wireless network capacity, data throughput rate, range and
coverage Performance depends on many factors, conditions and
variables, including distance from the access point, volume of
network traffic, building materials and construction, operating
system used, mix of wireless products used, interference and other
adverse conditions.
19
