Cisco Linksys RV042 User Manual

Linksys RV042 Setup
3
Instruction # 42-IS-0160, Rev A1
10. Enter 192.168.1.1 into the address bar.
11. A screen will appear and ask for the user name and password. Enter admin in the User
Name and
password fields. Click OK.
12. You will now see the router configuration screen. Click the Setup tab.
13. Under LAN setting, enter 192.168.191.254. Subnet mask should be 255.255.255.0. (This
is the MCE default setting. If the building IT department requires a different address
range, enter the assigned IP address here.)
14. Enter Host name and Domain name if required by your ISP.
15. Under WAN1, choose Static IP from the drop-down menu.

Cisco Linksys RV042 Specifications

General

WAN Ports	2
LAN Ports	4
VPN Tunnels	50
Form Factor	Desktop
Firewall	Yes
VPN Support	Yes
VPN Protocols	IPSec, PPTP
Firewall Type	SPI
Authentication	MD5, SHA1
QoS	Yes
Throughput	100 Mbps
Encryption	DES, 3DES, AES
Weight	0.5 kg
