Orange Initial link
Flashing orange
High availability not
complete
White High availability available
Internet Green
Port is configured as an
Internet uplink port
4
LAN Green
Port is configured as a
LAN port
Off No SFP connection
5 SFP connectivity
Green SFP connection
Additional functions on the front panel are described below, from left to right.
Reset button
Insert a paper clip if a reset is required.
• A brief, momentary press: To delete a downloaded
configuration and reboot.
• Press and hold for more than 10 sec: To force the
unit into a full factory reset.
USB port
USB 2.0 for 3G/4G wireless cards. Traffic status is
indicated by the USB LED.
SFP ports
Ports 10 and 11 are designed for SFP-SX (fiber) or SFP-
TX (RJ45 copper) GbE connectivity.
