Cisco Meraki MX64W User Manual

• Choose Web proxy > Yes.
• Enter values as appropriate for Hostname or IP and Port.
• If you require authentication, choose Authentication > Use authentication, and enter appropriate values for
Username and Password.
Configuring physical link settings
To configure physical link settings on the Ethernet ports, click Local status > Ethernet configuration. You can enable
half duplex, full duplex, and autonegotiation, as well as set 10- or 100-Mbps data rates.
To apply all configuration settings to the appliance, be sure to click Save Settings at the bottom of the page.
6

Cisco Meraki MX64W Specifications

General

Model	MX64W
Category	Firewall
WiFi	802.11ac
Firewall Throughput	250 Mbps
VPN Throughput	100 Mbps
Max VPN Tunnels	50
Advanced Security Throughput	100 Mbps
Concurrent Clients	50
Concurrent Connections	30, 000
Max concurrent clients	50
Max VPN peers	50
Wireless	802.11ac
LAN Interfaces	4 x GbE
Power	External power adapter
Weight	1.1 lbs
Ports	4 x GbE LAN, 2 x GbE WAN
