Cisco 7010 and Cisco 7505 Chassis Replacement Instructions 15
Replacing the Chassis
Figure 8 Ejector Levers and Captive Installation Screws
Interface processor
card slot
Interface processor card
carrier guide (black)
Ejector
lever
Captive
installation
screw
H1984
a
b
c
